Product Description
QuicRun 10BL60 SENSORED G2 Sensored Brushless ESC -Outstanding quality, amazing price Crafted for entry-level and intermediate builders, this ESC stands out with its exceptional quality and user-friendly design. It eliminates the complex setup, allowing users to jump right into action without the need for complicated tuning or trouble shooting. - Powerful built-in BEC Compared to the G1 ESC, the G2 ESC features a significant upgrade in its BEC output. The continuous output current has increased from 2A to 4A, with a peak current of up to 7A. With switchable output voltages of 6V/7.4V, it effortlessly powers high-torque and high-voltage servos, giving users a smooth and responsive control experience. -Support Boost/Turbo timing technology With support for Boost/Turbo timing adjustments of up to 24 degrees, this ESC unleashes maximum motor power, delivering an instant boost in speed when needed. -High reliability and durability A robust hardware foundation, combined with advanced software, equips this ESC with strong current resistance and an array of protective features—low voltage protection, over-temperature protection, throttle signal loss protection, overload protection and other functions. These safeguards significantly enhance its reliability and durability. -Support multiple programming methods The ESC supports three programming options: a multi-function LCD programming box, an LED programming box, and a SET button. This flexibility allows users to choose their preferred method for adjusting parameters with easy. -Supports Motor Rotation Adjustment With support for both counterclockwise (CCW) and clockwise (CW) motor steering adjustments, this ESC is compatible with a wide range of vehicle frames, ensuring versatility across different setups.
QuicRun 10BL60 Sensored
Product Number：30108000
Type：1/10th Brushless SD
Cont./Peak Current：60A/380A
Input Voltage：2-3S LiPo/6-9 Cell NiMH
BEC Output：Linear Mode:6V/2A
Input Wires：Red-12AWG-200mm*1/Black-12AWG-200mm*1
Output Wires：Blue-12AWG-200mm*1/Yellow-12AWG-200mm*1/Orange-12AWG-200mm*1
Input Connectors：No
Output Connectors：No
SET Button on ESC/LED Program Box：Supported
LCD Program Box/OTA Programmer/WiFi Module/Firmware Upgrade：Not Supported
Program Port：Program/Throttle Wire
Fan Size：25.0x25.0x10.0mm（0.984x0.984x0.394inches）
Fan Voltage Range：5-8.4V,Powered by BEC
Product Dimensions：33 x 28 x 31.5mm (w/ Fan)（1.3x1.1x1.24inches)
Product weight：59g
Applications
Motors：SL BL Motors/SD BL Motors
Vehicles：1/10th Touring Cars/Buggies/Drift Cars/F1
KV Rating/T Count：22S LiPo: 1/10th Touring Cars≥8.5T, 1/10th Buggies≥13.5T 3S LiPo: 1/10th Touring Cars≥13.5T, 1/10th Buggies≥17.5T (3650 Motors)
